Technical Specifications
Model | MR 300 |
---|---|
Shredded Feed width (mm) | 300-400 mm |
Shred size (mm) | Custom Made |
Shred Capacity | 250 strips per minute approx |
Voltage | 3 phase, 50 Hz, 415 V |
Power | 3 HP |
Weight (kgs) | 550 kgs (approx) |
Machines Dimensions (mm) HxWxD | 2000x1200x1500 (approx) |
Overload Protection | yes |
Overheat Protection | yes |
Auto Start/Off | online starter |
MOC | CR Tube structure with MS sheet covers, duly powder coated. All internal components and cutters are made from alloy steel. |
SEGREGATOR No. of decks Motor Rating Supply Input |
Single Deck 0.5 HP 3 phase, 50 HZ, 415 V |
MOC DETAILS Base Mesh Decks |
C.R. Steel SS 304 MS |
Working cycle if operated in ventilated ambience and at 60% rated capacity | continuous |
